Security

Monitor and Image

Monitor Setting

You can add multiple video streams using RTSP. To set it up, go to the Device > Monitor interface.

Monitor Display:
- Adaptive Multiple Windows: Display the monitor channels based on the number of added monitoring devices.
- Single Window: Display only one video monitoring channel.
- Four/Nine/Sixteen/Twenty-five Windows: Display 4/9/16/25 monitoring channels.

On the Device > Monitor > Door phone section, click +Add to add a monitor. The device supports displaying 25 monitoring channels at the same time.


Device Number: The device's SIP/IP number for identification.
Device Name: The device name for identification.
RTSP Address: The RTSP address of the monitoring device. RTSP format: rtsp://Device IP address/live/ch00_0.
Username: The username of the monitoring device for authentication.
Password: The password of the monitoring device for authentication.
Display In Call: Enable it to display the monitoring video during a call.

Note
You can import and export the monitoring device settings via a template in .xml format.

You can also set it up on the device Settings > Advance > Monitor screen. Tap the Add icon to add the monitor device.

Device Number: The device's SIP/IP number for identification.
Device Name: The device name for identification.
RTSP Address: The RTSP address of the monitoring device. RTSP format: rtsp://Device IP address/live/ch00_0.
Username: The username of the monitoring device for authentication.
Password: The password of the monitoring device for authentication.
Display In Call: Enable it to display the monitoring video during a call.
Scan: Tap to scan monitors on the same LAN through ONVIF.

View Monitoring Streams

After adding the monitored device’s RTSP URL, tap Monitor on the home screen and select the desired channel to view the stream.

You can zoom in and out of the video by tapping in the upper-right corner.

Video: Tap to make a video call to the monitored door phone.
Audio: Tap to make an audio call to the monitored door phone.
Unlock: Tap to open the door.
Capture: Tap to take a screenshot.
Cancel: Tap to exit the monitoring.
: Tap to display the monitor list.

RTSP Authentication

With RTSP authentication, users can monitor the indoor monitor via RTSP audio stream. This feature can be applied to, for example, listen to the baby in the baby’s room for safety.

To set it up, go to Settings > Basic interface.

Authorization Type: It is Digest by default.
Username: Set the username for the authentication.
Password: Set the password for the authentication.

Alarm and Arming Configuration

The Arming function is designed to enhance home security by offering three modes with custom zone settings for connected sensors. When armed, the device will sound a siren and notify specific people if a sensor detects something unusual.

Set up Location-based Alarm Sensors

To set up a location-based alarm sensor, go to the web Arming > Zone Setting > Zone Setting interface.

Location: Indicate where the alarm sensor is installed. There are ten location types: Bedroom, Gate, Door, Guest room, Hall, Window, Balcony, Kitchen, Study, and Bathroom.
Zone Type: The alarm sensor types.
Trigger Mode: Set sensor trigger mode between NC and NO.
Status: Set the alarm sensor status among three options: Enabled, Disabled, and 24H.
- Enabled: The alarm needs to be set again after disarming.
- Disabled: Disarm the alarm.
- 24H: The alarm sensor will stay enabled for 24 hours without setting up the alarm manually again after the alarm is disarmed.

If any of the zones are enabled or set to 24H, the alarm-related icons will be displayed on the home screen for quick access.

You can also set up alarm sensors on the Settings > Advance > Arming screen.

Select an Arming Mode

To select an arming mode, go to the Arming > Arming Mode interface.

Trigger Local Relay 1/2: Check it if you want the relay to be triggered with the arming mode switch.

Users can switch arming mode by tapping Arming on the home screen.

Set up Alarm Sensors in Different Arming Modes

To configure the alarm in different modes, go to the Arming > Arming Mode interface.

Location: Display which location the detection device is in, including Bedroom, Guest room, Hall, Window, Balcony, Kitchen, Study, and Bathroom.
Zone Type: Display the alarm sensor type.
Defence Delay: It means when users change the arming mode from other modes, there will be 90 seconds delay time to get activated.
Alarm Delay: It means when the sensor is triggered, there will be 90 seconds delay time to announce the notification.
Status: Enable or disable Arming Mode on the corresponding zone.

You can also set it up on the Arming > Arming Mode screen.

Set up the Disarm Codes

To configure the arming and disarm codes, go to the Arming > Disarm Code interface.

Disarm Interval(Sec): Set the alarm sound duration after the alarm is triggered.

You can also set it up on the Arming > Arming/Disarm Code screen.

Check Zone Status

Check the zone status on the Arming > Zone Status screen.

Check Alarm Logs

To check the alarm log, go to the Arming > Alarm Log screen.

Configure Alarm Text

Once the alarm sensor is configured, you can access the device's web interface to personalize the alert content displayed on the screen when an alarm is triggered.

To set it up, navigate to the web Arming > Zone Setting > Customized Alarm interface.

Alarm Content: The alarm text will be displayed on the device screen when an arming is triggered.

Configure Alarm Ringtone

You can upload a customized alarm ringtone by choosing the local audio file on the web Device > Audio > Alarm Ringtone Upload interface.

Note
The file format of customized ringtone should be in WAV or MP3 format. No limitation to the file size.

Alarm Action Configuration

When the alarm sensor is triggered, it can start different actions, such as HTTP commands, SIP messages, and calls.

To select and set up actions, go to the web Arming > Alarm Action interface.

HTTP Command

To set up the HTTP command action, you can select Enabled in the Send HTTP field to enable the actions for the alarm sensor installed in different locations. Then enter the HTTP command provided by the device manufacturer on which the action is to be carried.

Zone Type: Display the zone type set on the Arming > Zone Setting interface.
Send HTTP Enabled: Enable it if you want the action to be implemented on a designated third-party device.
HTTP Command: Enter the HTTP command provided by the third-party device manufacturer.
Send Delay: This option is only available when the Zone Type is Motion and Send HTTP is enabled. When enabled, the HTTP command will be sent in a delay time that is the same as the Alarm Delay set on the Arming > Arming Mode interface.

SIP Message

The device can send messages to a designated device when the alarm is triggered. To set this up, enter a SIP number or IP address along with the message content.

SIP Account: The SIP number to receive the message.
SIP Message: The message sent to the designated SIP number when the alarm is triggered.

SIP Call

To enable the device to make a call when the alarm is triggered, enter the SIP or IP number of the called party. Additionally, you can allow the indoor monitor to sound a siren simultaneously.

Call Number: The SIP number or IP number to receive the calls when the alarm is triggered.
Make Call Enable: Enable it so that a call will be made to the designated SIP or IP number when the alarm is triggered.
Alarm Siren: Enable it to trigger an alarm siren on the indoor monitor when the alarm is triggered.

Local Relay

You can select the local relay to be triggered by the alarm.

Zone Type: Display the zone type set on the Arming > Zone Setting interface.
Local Relay 1/2: Enable it if you want the local relay to be triggered with the sensor.
Open Delay: This option is only available when the Zone Type is Motion and Local Relay 1 is enabled. When enabled, the relay will be triggered in a delay time that is the same as the Alarm Delay set on the Arming > Arming Mode interface.

Screen Unlock Setting

To prevent unauthorized access to the device when it is not being used, enable the Screen Lock function. This feature automatically locks the device after a period of inactivity, requiring a password to unlock.

You can enable the screen lock function directly on the device Settings > Display screen.

Screen Unlock by PIN Code

To unlock the screen, users need to enter the preset PIN code.

Navigate to Settings > Advance Settings > Protect Code screen and select Settings Code to change the password.

Note
The default password is 123456.

Voice Encryption

Secure Real-time Transport Protocol (SRTP) is a protocol derived from the Real-time Transport Protocol (RTP). It enhances the security of data transmission by providing encryption, message authentication, integrity assurance, and replay protection.

To set it up, go to the Account > Advanced > Encryption interface.

Voice Encryption:
- Disabled: The call will not be encrypted.
- SRTP(Compulsory): All audio signals(technically speaking it is RTP streams) will be encrypted to improve security.
- SRTP(Optional): Encrypt the voice from the caller. If the caller also enables SRTP, the voice signals will also be encrypted.
- ZRTP(Optional): The protocol that the two parties use to negotiate the SRTP session key.

Remote Control

The remote control function allows a specific server to send HTTP commands or requests to the indoor monitor for actions like unlocking a local relay.

To set it up, navigate to the web Device > Relay > Remote Control interface.

Allowed Access IP List: Set up the server IP address that can be allowed to send the HTTP commands to the indoor monitor.

Web Interface Automatic Log-out

You can set up the web interface's automatic log-out timing, requiring re-login by entering the user name and the passwords for security purposes or for the convenience of operation.

To set it up, go to the web Security > Basic > Session Time Out interface.

Power Output Setting

The indoor monitor can serve as a power supply to the Akuvox door phone with a 12V power supply. You can enable the power output, then connect the door phone to the RJ45 port on the indoor monitor. Also, you can connect it to the 12V output port for the power supply.

To enable it, go to Settings > Basic > Power Output Setting interface.

High Security Mode

High security mode is designed to enhance the security. It employs encryption across various facets, including the communication process, door opening commands, password storage methods, and more.

To set it up, go to the web Security > Basic > High Security Mode interface.
