Akuvox V7.3.0 Smart Access Installer Guide - Commercial Projects

Update Time: Nov. 2025

About This Manual

This manual is intended for installers who need to manage companies, personnel, devices, and more on the Akuvox Smart Access Cloud(Version: 7.3.0).

This manual applies to commercial projects that are created after October 15, 2024.

For more information, please visit http://www.akuvox.com/ or consult Akuvox technical support.

What's New in 7.3.0:

• Support adding single-company projects.

• Support paying for a specific door.

• Optimized batch import of devices and personnel to sites.

System Overview

You can use this platform to:

• Add, edit, and delete the companies, devices, administrators, and personnel.

• Deploy and set up devices and doors for access control.

• Check and upgrade device firmware.

• Check and manage the MAC library.

• Conduct remote operations such as auto-provisioning, device reboot, transmission type modification, and remote maintenance.

• Subscribe and renew the cloud service.

• Manage sub-installer accounts.

Login

You can log in to the cloud platform using the account obtained from your distributor.

1. Open the web browser, enter the address (URL) of the server location in your area, and press Enter.

2. Enter your username and password.

3. Click Login.

Note

Enter a verification code for login if your distributor enables the two-factor authentication.

Log Out

Click Log out in the upper right corner to exit the system.

Email Confirmation

You are required to enter an email address when you log in to the cloud platform.

The email address is used to reset your login password and to receive notifications from Akuvox.

You can change the email address and turn off the notification push on the Setting > Notification interface.

Note

Click here to view how to reset the login password using the email address.

Prior to the Management

It is advised that you go through what is listed below before starting your management.

• Check if all device MAC addresses have already been registered by your distributor.

• Check if the device firmware supports cloud mode with no connection to SDMC.

• Check if the device is powered on and is connected to the internet, and make sure that the network is normal.

• Check and make sure that the user information and device information are correct.

Dashboard

The functional columns allow you to manage sites, users, devices, and account settings in an organized manner.

Module Description:

Site Management

The cloud system offers two types of sites.

• Single-Company Site: Easy and streamlined setup. Ideal for small businesses such as stores, restaurants, startups, and other simple scenarios.

• Multi-Company Site: Support the creation of multiple companies. Designed for projects that require more complex permission isolation and configuration.

Add a Site

Add sites on the Site module or through the Quicklinks on the Dashboard.

On the Sites module,

1. Select Commercial and click +New.

2. Choose Single-Company Site or Multi-Company Site.

3. Set up the project. See details in the chart below.

4. You can add project managers and set up their permissions immediately after the site is created.

   Or, click Set Later to add PMs when editing the site.

5. Select the project manager from the list, or create a new account by clicking +New Project Manager.

6. Set whether the PM has permission to pay the cloud service fee for the site. This option displays when you have permission to pay.

7. Set whether to send the service expiration and renewal emails to the PM. Disabled by default.

8. Submit the setting.

Edit and Delete Sites

1. On the Sites module, clickof the desired site.

2. Set up additional settings. See details in the chart below.

3. To delete the site, click Delete at the bottom.

Batch Import Devices and Personnel to Sites

You can use templates to improve the efficiency of adding devices and personnel to sites.

1. Click Download The Template on the Sites module.

2. Select the template based on your project type: single-company, multi-company, or old version(created before Oct.15, 2024) projects.

3. Enter the information in the template. See input instructions by hovering your mouse cursor over specific columns.

4. Click to import the template.

Project Management

After creating sites, click of the specific project to manage the companies, personnel, administrators, devices, etc in the project.

Please refer to the following manuals for instructions.

• Akuvox Smart Access Single-Company Management Guide

• Akuvox Smart Access Multi-Company Management Guide

Add Project Manager Account

You can create a project manager account and assign it to a specific commercial project.

1. Click Users on the left column and click New PM on the right.

2. Fill in the PM information and select the language of the email sent to the PM.

3. Enable or disable the Monthly Password Update Reminder and Email Two-Factor Authorization for Login.

• Monthly Password Update Reminder: If enabled, when PMs log in to the cloud platform, they will see a prompt every month reminding them to change their SmartPlus login passwords. This feature is used to enhance the security of PM accounts.

• Email Two-Factor Authorization for Login: If enabled, when PMs log in to the cloud platform, they need to enter their email addresses and fill in a verification code for login.

4. Choose the project(s) that are managed by the PM. Move them from the left to the right box.

You can also assign PMs to projects on the Sites interface.

1. Click  of the project.

2. Select PMs from the dropdown menu.

Edit/Delete Project Manager Account

You can edit and delete the PM account.

1. Go to the Users module and select PM.

2. Click to edit the PM account information and reset its password.

Batch Import Project Manager Accounts

You can add/edit PM accounts in a batch to improve efficiency.

1. On the Users module, click Import on the right.

2. Click Download Template.

Note

• The email is a credential corresponding to the existing PM account and cannot be modified.

• For example, if you want to change the language of a certain account while keeping other items unchanged, select the target language in the file, enter the email of that account, and leave other items blank.

3. Edit the template. Enter the first name and last name of the PM.

4. Enter the email address to receive the account activation email. It is mandatory and cannot be modified for the existing PM.

5. Select the language of the email from the available options.

6. Enter the commercial project name(s) to be managed.

• You can ONLY fill in one project name in one row. If the PM manages multiple projects, use separate rows.

• You can ONLY enter the project(s) that have been created.

• You can check the instructions by moving your mouse cursor to the columns.

7. Click Batch Add/Edit Project Manager and upload the file. The importing result will then display.

Firmware Management

You can check and update the device firmware version in the Firmware module and Upgrade module, respectively.

Check Firmware List

Before upgrading device firmware, you can go to the Firmware module to check the latest available for uploading.

Firmware List Description

Upgrade Firmware

You can upgrade the device firmware to the selected version according to the update timing defined.

1. Go to the Upgrade module.

2. Click New.

3. Select Commercial as the project type and choose the site.

4. Select the firmware version and the device to be upgraded.

5. Select the time to upgrade the device.

6. You can check Reset After Upgrade to reset the device's configuration after upgrading finishes.

Check and Edit the Firmware Upgrade List

After upgrading the device firmware, you can not only check your firmware update status but also edit the update settings for devices pending the upgrade. And you can delete the specific record as well.

1. Search the firmware status by All, Pending, Processing, and Executed.

2. Edit the update set for the devices pending the update.

3. Delete the specific update record if needed.

Update List Description

Note

After initiating the specific firmware update, refresh the window to update the firmware list.

Subscriptions

You need to pay for the commercial projects created after June 1, 2025. For these projects, you can pay with credits assigned by your distributors.

The following services require payment.

• Doors(The first door is free to use. Using more requires payment.)

• Personnel’s SmartPlus App accounts with smart intercom and landline services.

• Administrators’ SmartPlus App accounts.

• Premium Plan: Attendance feature.

Note

• If doors expire or are not activated, the cloud services of these doors will be limited. For example, access methods cannot be issued to the device, and the device cannot report alarms to the cloud.

• When a door is deleted, it will free up a slot for a free door. When a door is enabled, it will take the available slot.

Quotation Generator

The quotation generator helps you calculate the one-time or monthly fees of specific projects.

1. Click the Calculator icon in the upper right corner.

2. Select Commercial.

3. Set the project features and select item numbers.

• Number of Apps without Intercom Feature for Personnel: The number of SmartPlus App accounts used by personnel without intercom features.

• Number of Apps with Intercom Feature for Personnel: The number of SmartPlus App accounts used by personnel with intercom features.

• Number of Personnel with Landline Service: The number of personnel who use the landline service.

• Number of Admin Apps: The number of SmartPlus App accounts used by company administrators.

• Number of Admins with Landline Service: The number of company administrators who use the landline service.

• Attendance Plan:

  • Off: Disable the feature.

  • 100 Personnel Package: Arrange shifts for 100 personnel at a maximum.

  • Unlimited Personnel Package: Arrange shifts for an unlimited number of personnel.

4. Click Calculate to generate the fee.

Activate Services

1. Click Subscriptions and select Commercial as the project type.

2. Click Next > Activate.

3. Select Site and Service Type.

4. Check the item(s).

5. Click Next.

6. Complete the billing information by clicking before clicking Pay.

Renew Services

1. Click Subscriptions and select Commercial as the project type.

2. Click Next > Renew.

3. Select Site and Service Type. You can also select the expiration time to narrow the search scope.

4. Check the item(s).

5. Set the renewal period with a maximum of 5 years.

6. Click Next.

7. Complete the billing information by clicking before clicking Pay.

Transaction History

The Payments module allows you to search, check, and delete the transaction history.

You can click to view the order details and download the invoice.

Sub-Installer Account Management

When several people are responsible for one project, you can create and log in to different sub-installer accounts of the same main account at the same time. The data shown are the same.

Add Sub-Installer Account

1. Click the Users module and click Sub Account.

2. Click New Sub Account on the right.

3. Enter the account's information. The SmartPlus portal login password will be sent to the email address.

Edit/Delete Sub-Installer Account

1. Click to edit the sub-account information and reset the password.

2. Click to delete the account.

Installer Account Management

You can change the account password, time zone, and billing information.

Change Installer Account Password

1. Click your account name in the upper right corner.

2. Click Change Password.

3. Change the password.

Change Time Settings

Click Setting > Time to set up the time settings.

Set Account Access Permission

You can grant permission to your distributor to log in to your account without a password. With permission, distributors can switch to your account from their web portal to give you support or assistance. The account settings will be displayed in the drop-down list once the distributor enables the account access feature.

You can turn on or off the permission whenever you need.

1. Click Setting and select Account Setting.

2. Disable/enable the permissions.

Note

The account setting will only appear once your distributor enables the account access feature. By default, the Permission Granted feature is turned on.

Billing Information

You are required to fill in your billing information so that your distributor will be able to send you the bill according to the information you filled in.

Click Setting > Billing Information and enter the information.

Log Control

You can control whether to display captured images or recorded videos in call logs.

Click Setting > Log Setting to set it up. Enable/disable Call History Snapshots. It is enabled by default.

Credit Logs

Akuvox supports using credit to activate and renew SmartPlus services. After your distributors assign credits to you, you can use them for payment.

Check your available credits by clicking Setting > Credit Logs.

Note

ONLY commercial projects created after June 1, 2025, support credit payment.

Customer Service

Customer service allows customers to contact you through the information you entered on the SmartPlus installer portal.

1. Click Setting and select Customer Service.

2. Enter or modify your phone number and email address.

3. Enable Receive Feedback if needed, and end users' feedback will be sent to the email address that you fill in.

Privacy Policy

You will see the Privacy Policy window when you log into the platform for the first time.

The Privacy Policy tells you how the user data is collected, used, and protected.

• When you click Agree, you will be guided to the Service Provider Information interface to fill in your information. The information will be displayed in the privacy policy for end users. It is not mandatory to fill it out. Not filling it in will not affect your use of SmartPlus cloud services.

• When you click Disagree, you cannot log in to the SmartPlus platform.

You can also click Privacy Policy in the left column to view the agreement again.

Contact Us

For more information about the product, please visit us at www.akuvox.com, or feel free to contact us by

Sales email: sales@akuvox.com

Technical support email: support@akuvox.com

Telephone: +86-592-2133061 ext.7694/8162

We highly appreciate your feedback about our products.
